Validating FileUpload Control for Specific File Type and Required Field.


In this article I am going to explain how we can check and validate user for uploading only certain files and making uploading of file to be must for submission of form.


For validating for required field we have to use RequiredFieldValidator and for validating for file types we’ll have to use RegularExpressionValidator. But, before starting we should have brief idea about the controls required.


Before starting about validating FileUpload we must have brief idea about FileUpload control and Validation Controls of ASP.Net


FileUpload Control:


FileUpload control is used for uploading file to the server from the client side.


For detailed reading about FileUpload visit:


https://www.mindstick.com/Articles/176/fileupload-control-in-asp-dot-net

http://msdn.microsoft.com/en-us/library/system.web.ui.webcontrols.fileupload.aspx

RequiredFieldValidator:

With this control, the validation fails if the input value does not change from its initial value. By default, the initial value is an empty string ("").

For more details visit: https://www.mindstick.com/Articles/195/requiredfieldvalidator-control-in-asp-dot-net


RegularExpressionValidator:


The RegularExpressionValidator control is used to ensure that an input value matches a specified pattern. The validation will not fail if the input control is empty. Use the RequiredFieldValidator control to make the field required.



For more details about RegularExpressionValidator visit following link:


https://www.mindstick.com/Articles/197/regularexpressionvalidator-control-in-asp-dot-net


Validating FileUpload Control in ASP.Net


Validating File Upload Control certain file types. Here in the example below I am using RegularExpressionValidator to accomplish my task.


<asp:FileUpload ID="FileUpload1" runat="server" />



<asp:RegularExpressionValidator ID="RegularExpressionValidator1" runat="server" ErrorMessage="Only .doc , .docx or .txt files are allowed."

ValidationExpression="^(([a-zA-Z]:)|(\\{2}\w+)\$?)(\\(\w[\w].*))+(.doc|.docx|.txt)$"

ControlToValidate="FileUpload1">*</asp:RegularExpressionValidator>



Here, regular expression for .doc,  .docx,  .txt files is:

"^(([a-zA-Z]:)|(\\{2}\w+)\$?)(\\(\w[\w].*))+(.doc|.docx|.txt)$"

If you want some more or other files type to be uploaded then you can replace or add more extension with the above mentioned extensions. Suppose you want your user to upload only .pdf file then you Regular expression for that will be:

"^(([a-zA-Z]:)|(\\{2}\w+)\$?)(\\(\w[\w].*))+(.pdf)$"

But, this does not mean that user will be forced to upload file, this validation is only performed if user tries to upload file. If you want to make uploading of file mandatory then you have to use Required Field Validator.

<asp:RequiredFieldValidator ID="RequiredFieldValidator1" runat="server" ErrorMessage="You have not uploaded your file" ControlToValidate="FileUpload1">* </asp:RequiredFieldValidator>



The code above will validate FileUpload1 for required field.


Validation

By John Smith on   5 years ago
Really useful Article Haider.

Validator syntax in my script

By Shoeb Khan on   4 years ago
Hi,

In my script below, where would I paste the validator?

<%@ Page Language="VB" %>
<%@ Import Namespace="System.IO" %>
<!DOCTYPE html PUBLIC "-//W3C//DTD XHTML 1.0 Transitional//EN" "http://www.w3.org/TR/xhtml1/DTD/xhtml1-transitional.dtd">

<script runat="server" >

    Protected Sub btnUpload_Click(ByVal sender As Object, ByVal e As System.EventArgs) Handles btnUpload.Click
        LblError.Visible = False
        Dim strUploadsDirectoryPath As String = Session("FileUploadPath")
        Dim strLatestGenPONum As String = Session("LatestGeneratedPONum")
        Dim strCompleteFilepath As String = filUpload.PostedFile.FileName
        Dim strActualFileName As String = System.IO.Path.GetFileName(strCompleteFilepath)
        Dim myFileinfo As New FileInfo(strUploadsDirectoryPath & "\" & strLatestGenPONum & strActualFileName)

        LblError.Text = ""

        If strActualFileName = "" Then
            LblError.Visible = True
            LblError.Text = "Please enter a valid Resource or Browse to the location"
            Session("FileUploadStatus") = "False"
        Else
            Try

                If myFileinfo.Exists = False Then
            Dim fso, f
                     fso = CreateObject("Scripting.FileSystemObject")
            If fso.FolderExists(strUploadsDirectoryPath + strLatestGenPONum) = false Then
            f = fso.CreateFolder(strUploadsDirectoryPath + strLatestGenPONum)
            End If

            filUpload.PostedFile.SaveAs(strUploadsDirectoryPath + strLatestGenPONum + "\" + strActualFileName)
                LblError.Visible = True
                    LblError.Text = "File physically Uploaded. Please remember to - confirm your attachment..."
                    Session("FileUploadStatus") = "True"
                    Session("DocumentName") = strActualFileName

                Else
                    LblError.Visible = True
                    LblError.Text = "Uploaded file already exists"
                    Session("FileUploadStatus") = "False"
                    Session("DocumentName") = ""
                End If

            Catch ex As Exception

                LblError.Visible = True
                LblError.Text = ex.ToString()
                Session("FileUploadStatus") = "False"

            End Try

        End If



    End Sub

</script>

<html xmlns="http://www.w3.org/1999/xhtml" >
<head runat="server">
    <title>Upload File</title>
    <style runat="server">
        .buttonStyleNew{
        border:2px solid #333333;
        font-size:12px;
        color:#FFFFFF;
        background-color:#656565;
        font-family:Arial, Helvetica, sans-serif;
        }
        .UploadNew{
        border:2px solid #333333;
        font-size:12px;
        color:#FFFFFF;
        font-family:Arial, Helvetica, sans-serif;
        }
    </style>
</head>
<body>
    <form id="FrmUpload" runat="server" method="post">
    <div>

    <asp:FileUpload runat="server" ID="filUpload" CssClass="UploadNew" Width="364px" ForeColor="Black" />&nbsp;&nbsp;&nbsp;&nbsp;<asp:Button ID="btnUpload" runat="server" Text="Upload File" CssClass="buttonStyleNew"/><br />
        &nbsp;<asp:Label runat="server" ID="LblError" Visible="false" ForeColor="red" Font-Size="small" Font-Bold="false"></asp:Label></div>
    </form>
</body>
</html>

Validating FileUpload control for specific file type and required field.

By Haider M Rizvi on   4 years ago

Hi Shoeb Khan,

You can use paste your validator anywhere between <body> </body> tag, all you need to do is to pass the name of your FileUpload control in ControlToValidate property of validator.

<asp:FileUpload runat="server" ID="filUpload" CssClass="UploadNew" Width="364px" ForeColor="Black" />

<asp:RegularExpressionValidator ID="RegularExpressionValidator1"runat="server"ErrorMessage="Only .doc , .docx or .txt files are allowed." ValidationExpression="^(([a-zA-Z]:)|(\\{2}\w+)\$?)(\\(\w[\w].*))+(.doc|.docx|.txt)$" ControlToValidate="filUpload">*</asp:RegularExpressionValidator>

Hope this will solve your problem.


Validating FileUpload control for specific file type and required field.

By Shoeb Khan on   4 years ago
Below is the changes I have made. It works, but the error message is not displayed. It only display '*' if wrong file type is selected.


<%@ Page Language="VB" %>
<%@ Import Namespace="System.IO" %>
<!DOCTYPE html PUBLIC "-//W3C//DTD XHTML 1.0 Transitional//EN" "http://www.w3.org/TR/xhtml1/DTD/xhtml1-transitional.dtd">

<script runat="server" >

    Protected Sub btnUpload_Click(ByVal sender As Object, ByVal e As System.EventArgs) Handles btnUpload.Click
        LblError.Visible = False
        Dim strUploadsDirectoryPath As String = Session("FileUploadPath")
    Dim strPOYear As String = Session("POYear")
        Dim strLatestGenPONum As String = Session("LatestGeneratedPONum")
        Dim strCompleteFilepath As String = filUpload.PostedFile.FileName
        Dim strActualFileName As String = System.IO.Path.GetFileName(strCompleteFilepath)
        Dim myFileinfo As New FileInfo(strUploadsDirectoryPath & strPOYear & "\" & strLatestGenPONum & "\" & strActualFileName)
    'Response.Write("PATH : " & strUploadsDirectoryPath & strPOYear & "\" & strLatestGenPONum & "\" & strActualFileName)

        LblError.Text = ""

        If strActualFileName = "" Then
            LblError.Visible = True
            LblError.Text = "Please enter a valid Resource or Browse to the location"
            Session("FileUploadStatus") = "False"
        Else
            Try

                If myFileinfo.Exists = False Then
            Dim fso, f
                     fso = CreateObject("Scripting.FileSystemObject")
            If fso.FolderExists(strUploadsDirectoryPath + strPOYear + "\" + strLatestGenPONum) = false Then
            f = fso.CreateFolder(strUploadsDirectoryPath + strPOYear + "\" + strLatestGenPONum)
            End If

            filUpload.PostedFile.SaveAs(strUploadsDirectoryPath + strPOYear + "\" + strLatestGenPONum + "\" + strActualFileName)
                LblError.Visible = True
                    LblError.Text = "File physically Uploaded. Please remember to - confirm your attachment..."
                    Session("FileUploadStatus") = "True"
                    Session("DocumentName") = strActualFileName

                Else
                    LblError.Visible = True
                    'LblError.Text = "Uploaded file already exists"
            LblError.Text = "file already exists..Overwriting"
                    'Session("FileUploadStatus") = "False"
                    'Session("DocumentName") = ""
            Session("FileUploadStatus") = "True"
                    Session("DocumentName") = strActualFileName
                End If

            Catch ex As Exception

                LblError.Visible = True
                LblError.Text = ex.ToString()
                Session("FileUploadStatus") = "False"

            End Try

        End If



    End Sub

</script>


<html xmlns="http://www.w3.org/1999/xhtml" >
<head runat="server">
    <title>Upload File</title>
    <style runat="server">
        .buttonStyleNew{
        border:2px solid #333333;
        font-size:12px;
        color:#FFFFFF;
        background-color:#656565;
        font-family:Arial, Helvetica, sans-serif;
        }
        .UploadNew{
        border:2px solid #333333;
        font-size:12px;
        color:#FFFFFF;
        font-family:Arial, Helvetica, sans-serif;
        }
    </style>
</head>
<body>
    <form id="FrmUpload" runat="server" method="post">
   <div>
<asp:FileUpload ID="filUpload" runat="server" CssClass="UploadNew" Width="364px" ForeColor="Black" />&nbsp;&nbsp;&nbsp;&nbsp;<asp:Button ID="btnUpload" runat="server" Text="Upload File"

CssClass="buttonStyleNew"/><br />&nbsp;<asp:Label runat="server" ID="LblError" Visible="False" ForeColor="red" Font-Size="small" Font-Bold="false"></asp:Label><asp:RegularExpressionValidator

ID="RegularExpressionValidator1" runat="server" ErrorMessage="Only .doc , .docx or .txt files are allowed." ValidationExpression="^(([a-zA-Z]:)|(\\{2}\w+)\$?)(\\(\w[\w].*))+

(.doc|.docx|.txt|.pdf|.xls|.xlsx|.ppt|.zip|.jpg|.png|.tiff|.PDF|.DOC|.DOCX|.JPG|.JPEG|.jpeg|.XLS|.XLSX|.PPT|.ZIP|.RAR|.rar|.TIFF)$" ControlToValidate="filUpload">*</asp:RegularExpressionValidator> </div>
    </form>
</body>
</html>

Validating FileUpload control for specific file type and required field.

By Haider M Rizvi on   4 years ago

All you need to do is to remove * from the validator.

Instead of validator below :

<asp:RegularExpressionValidator ID="RegularExpressionValidator1" runat="server" ErrorMessage="Only .doc , .docx or .txt files are allowed." ValidationExpression="^(([a-zA-Z]:)|(\\{2}\w+)\$?)(\\(\w[\w].*))+(.doc|.docx|.txt)$" ControlToValidate="filUpload">*</asp:RegularExpressionValidator>

Use this:

<asp:RegularExpressionValidator ID="RegularExpressionValidator1" runat="server" ErrorMessage="Only .doc , .docx or .txt files are allowed." ValidationExpression="^(([a-zA-Z]:)|(\\{2}\w+)\$?)(\\(\w[\w].*))+(.doc|.docx|.txt)$" ControlToValidate="filUpload"></asp:RegularExpressionValidator>

The only difference in both of them is that one have “*” sign and another don’t have.


Validating FileUpload control for specific file type and required field

By Shoeb Khan on   4 years ago
Thats great......Thanks for all that support. Much appreciated :)

Let me know if I can ask for a VB code for a  calendar (not a dropdown calendar)

Asking questions.

By Haider M Rizvi on   4 years ago

You can ask you question in our forum section.

http://www.mindstick.com/mindForum/Topic.aspx


Validating FileUpload control for specific file type and required field

By Shoeb Khan on   4 years ago
The script works fine. But after upload is successful, the message 'only .doc,............' appears again, which i want to avoid.


Validating FileUpload control for specific file type and required field

By Haider M Rizvi on   4 years ago
Hi Shoeb,

I think you must have missed something.
Could you please post your latest code here.

Thanks,

Validating FileUpload control for specific file type and required field

By Shoeb Khan on   4 years ago
Hi Haider,

here it is...

-------


<%@ Page Language="VB" %>
<%@ Import Namespace="System.IO" %>
<!DOCTYPE html PUBLIC "-//W3C//DTD XHTML 1.0 Transitional//EN" "http://www.w3.org/TR/xhtml1/DTD/xhtml1-transitional.dtd">

<script runat="server" >

    Protected Sub btnUpload_Click(ByVal sender As Object, ByVal e As System.EventArgs) Handles btnUpload.Click
        LblError.Visible = False
        Dim strUploadsDirectoryPath As String = Session("FileUploadPath")
    Dim strPOYear As String = Session("POYear")
        Dim strLatestGenPONum As String = Session("LatestGeneratedPONum")
        Dim strCompleteFilepath As String = filUpload.PostedFile.FileName
        Dim strActualFileName As String = System.IO.Path.GetFileName(strCompleteFilepath)
        Dim myFileinfo As New FileInfo(strUploadsDirectoryPath & strPOYear & "\" & strLatestGenPONum & "\" & strActualFileName)
    Response.Write("PATH : " & strUploadsDirectoryPath & strPOYear & "\" & strLatestGenPONum & "\" & strActualFileName)

        LblError.Text = ""

        If strActualFileName = "" Then
            LblError.Visible = True
            LblError.Text = "Please enter a valid Resource or Browse to the location"
            Session("FileUploadStatus") = "False"
        Else
            Try

                If myFileinfo.Exists = False Then
            Dim fso, f
                     fso = CreateObject("Scripting.FileSystemObject")
            If fso.FolderExists(strUploadsDirectoryPath + strPOYear + "\" + strLatestGenPONum) = false Then
            f = fso.CreateFolder(strUploadsDirectoryPath + strPOYear + "\" + strLatestGenPONum)
            End If

            filUpload.PostedFile.SaveAs(strUploadsDirectoryPath + strPOYear + "\" + strLatestGenPONum + "\" + strActualFileName)
                LblError.Visible = True
                    LblError.Text = "File physically Uploaded. Please remember to - confirm your attachment..."
                    Session("FileUploadStatus") = "True"
                    Session("DocumentName") = strActualFileName

                Else
                    LblError.Visible = True
                    LblError.Text = "Uploaded file already exists"
                    Session("FileUploadStatus") = "False"
                    Session("DocumentName") = ""

                End If

            Catch ex As Exception

                LblError.Visible = True
                LblError.Text = ex.ToString()
                Session("FileUploadStatus") = "False"

            End Try

        End If



    End Sub

</script>

<html xmlns="http://www.w3.org/1999/xhtml" >
<head runat="server">
    <title>Upload File</title>
    <style runat="server">
        .buttonStyleNew{
        border:2px solid #333333;
        font-size:12px;
        color:#FFFFFF;
        background-color:#656565;
        font-family:Arial, Helvetica, sans-serif;
        }
        .UploadNew{
        border:2px solid #333333;
        font-size:12px;
        color:#FFFFFF;
        font-family:Arial, Helvetica, sans-serif;
        }
    </style>
</head>
<body>
    <form id="FrmUpload" runat="server" method="post">
   <div>
<asp:FileUpload ID="filUpload" runat="server" CssClass="UploadNew" Width="364px" ForeColor="Black" />&nbsp;&nbsp;&nbsp;&nbsp;<asp:Button

ID="btnUpload" runat="server" Text="Upload File" CssClass="buttonStyleNew"/><br />&nbsp;<asp:Label runat="server" ID="LblError" Visible="False"

ForeColor="red" Font-Size="small" Font-Bold="false"></asp:Label><asp:RegularExpressionValidator ID="RegularExpressionValidator1" runat="server"

ErrorMessage="Only .doc , .docx, .xls, .xlsx, .pdf, .jpg or .txt files are allowed." ValidationExpression="^(([a-zA-Z]:)|(\\{2}\w+)\$?)(\\(\w

[\w].*))+(.doc|.docx|.txt|.pdf|.xls|.xlsx|.ppt|.zip|.jpg|.png|.tiff|.PDF|.DOC|.DOCX|.JPG|.JPEG|.jpeg|.XLS|.XLSX|.PPT|.ZIP|.RAR|.rar|.TIFF)$"

ControlToValidate="filUpload"></asp:RegularExpressionValidator> </div>
    </form>
</body>
</html>

Validating FileUpload control for specific file type and required field

By Haider M Rizvi on   4 years ago

Hi Shoeb,

Try this:

<asp:RegularExpressionValidator ID="RegularExpressionValidator1" runat="server" ErrorMessage="Only .doc , .docx or .txt files are allowed." ValidationExpression="^(([a-zA-Z]:)|(\\{2}\w+)\$?)(\\(\w[\w].*))+(.doc|.docx|.txt|.pdf|.xls|.xlsx|.ppt|.zip|.jpg|.png|.tiff|.PDF|.DOC|.DOCX|.JPG|.JPEG|.jpeg|.XLS|.XLSX|.PPT|.ZIP|.RAR|.rar|.TIFF)$" ControlToValidate="filUpload"></asp:RegularExpressionValidator>



Note: Remove spaces(if any) within ValidationExpression.


Validating FileUpload control for specific file type and required field

By Shoeb Khan on   4 years ago
still getting the same result


Validating FileUpload control for specific file type and required field

By Haider M Rizvi on   4 years ago
I am unable to reproduce the error. Here is the code which I am using in my HTML Body. Have a look.


Validating FileUpload control for specific file type and required field

By Shoeb Khan on   4 years ago
if you see my code, i have
      LblError.Visible = True
                    LblError.Text = "File physically Uploaded. Please remember to - confirm your attachment..."

which gets visible once's the file is successfully uploaded and i think this makes all the error visible at that time

Validating FileUpload control for specific file type and required field

By Haider M Rizvi on   4 years ago
Here is the code which I had written on click of Upload button.


Have a look at the above code.

Don't want to miss updates? Please click the below button!

Follow MindStick
